| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRF |
| Moc maksymalna | 200 W |
| Max. current | 11.7 A |
| Short-circuit current | 12.3 A |
| Solar cell efficiency | 23 % |
| Solar cell lamination | ETFE |
| Max. system voltage | 500 V d.c. |
| Voltage for max. power | 17.1 V d.c. |
| Open circuit voltage | 20.4 V d.c. |
| Unfolded dimensions | 2233x588x35 mm |
| Folded dimensions | 600x588x85 mm |
| Transportation holder | yes |
| Fold | yes |
| Solar cable length | 2 m |
| Working temperature | -20 ~ +60 ˚C |
| Protection grade | IP67 |
| Weight | 6 kg |
| Set includes | solar panel, MC4 adapter (DC7909, DC8020, XT60, Anderson) |
| Compatible with | YT-83090, YT-83091, YT-83092 |
| Symbol | YT-98201 |
A foldable solar panel with an output power of 200 watts is a portable source of energy. The ETFE solar cell lamination guarantees resistance to weather conditions. Adjustment of the brackets allows you to position the panel conveniently in relation to the sunlight or hang it in a chosen location using mounting holes. When folded, the panel has compact dimensions, which combined with built-in handles make it easy to carry.
The set includes a 4-in-1 adapter, which allows you to connect devices with DC7909, DC8020, XT60, and Anderson connectors. Compatible with portable power stations: YT-83090, YT-83091, YT-83092.
- power: 200 W
- cell efficiency: 23%
- cell lamination: ETFE
- power voltage and current: 17.1 V/11.7 A
- protection class: IP67
- dimension when folded: 600 x 588 x 85 mm
- dimension when unfolded: 2233 x 588 x 35 mm
- operating temperature: -20 ~ +60˚C
- hanging loops
- solar cable length: 2 m
- weight: 6 kg
Usage warnings:
Warning! Electrical hazard. This unit produces direct current when exposed to the light. Connect panel to the load before exposing to the sun.
