| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRF |
| Moc maksymalna | 100 W |
| Max. current | 5.85 A |
| Short-circuit current | 6.17 A |
| Solar cell efficiency | 23 % |
| Solar cell lamination | ETFE |
| Max. system voltage | 500 V d.c. |
| Voltage for max. power | 17.1 V d.c. |
| Open circuit voltage | 20.4 V d.c. |
| Unfolded dimensions | 1196x588x35 mm |
| Folded dimensions | 592x588x55 mm |
| Transportation holder | yes |
| Fold | yes |
| Solar cable length | 2 m |
| Working temperature | -20 ~ +60 ˚C |
| Protection grade | IP67 |
| Weight | 3.4 kg |
| Set includes | solar panel, MC4 adapter (DC7909, DC8020, XT60, Anderson) |
| Compatible with | YT-83090, YT-83091, YT-83092 |
| Symbol | YT-98200 |
A folding solar panel with an output power of 100 watts is a portable source of energy. The ETFE solar cell lamination guarantees resistance to weather conditions. Adjustment of the brackets allows you to position the panel conveniently relative to the sunlight or hang it in a chosen location thanks to four mounting holes. The panel has compact dimensions when folded, which combined with built-in handles make it easy to carry.
The set includes a 4-in-1 adapter, with which you can connect devices with DC7909, DC8020, XT60, and Anderson connectors. Compatible with portable power stations: YT-83090, YT-83091, YT-83092.
- power: 100 W
- efficiency of cells: 23%
- cell lamination: ETFE
- voltage and current: 17.1 V/5.85 A
- protection level: IP67
- dimension when folded: 592 x 588 x 55 mm
- dimension when unfolded: 1196 x 588 x 35 mm
- operating temperature: -20 ~ +60˚C
- suspension eyelets
- solar cable length: 2 m
- weight: 3.4 kg
Usage warnings:
Warning! Electrical hazard. This unit produces direct current when exposed to the light. Connect panel to the load before exposing to the sun.
