| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRF |
| Moc maksymalna | 4000 (S2 5 min) W |
| Power | 3800 W |
| Voltage | 230 V a.c. |
| Frequency | 50 Hz |
| Engine (motor) capacity | 224 cm³ |
| Fuel tank capacity | 8.3 l |
| Fuel type | unleaded petrol |
| Oil tank capacity | 0.55 l |
| Oil type | SAE 15W-40 |
| Direct current | 16.5 A |
| Alternating current | 8.3 A |
| Wheels | yes |
| Wheel quantity | 2 |
| Transportation holder | yes |
| Handle quantity | 1 |
| Dimensions | 590x456x511 mm |
| Boot type | manual, electric |
| Cooling | air |
| Engine (motor) type | R225-V |
| Ignition plug type | F6RTC |
| Max. engine (motor) power | 5.3 kW |
| Max. engine (motor) rotations | 3600 min⁻¹ |
| Cylinders number in engine (motor) | 1 |
| Strokes number in engine (motor) | 4 |
| Compression stage | 8.0:1 |
| Power factor | 1 |
| Working temperature range | 0~40 ˚C |
| Max. operating altitude | 1000 m n.p.m. |
| Quality class | B |
| Performance class | G2 |
| Electric insulation class | I |
| Protection grade | IP23M |
| Acoustic pressure | 71.7 ± 1.90 dB(A) |
| Acoustic power | 91.7 ± 1.90 dB(A) |
| Weight | 45 kg |
| Set includes | generator, pilot |
| Symbol | YT-85485 |
The petrol generator is a reliable source of energy in recreational plots, campsites, summer houses, and everywhere where there is no access to electricity or where the use of emergency electrical power is necessary. The inverter power system allows safe connection of even sensitive electronic devices and equipment.
Generator:
- power: 3800 W
- maximum power: 4000 W (S2 5 min)
- voltage: 230 V, 5, 12 V d.c.
- frequency: 50 Hz
- power factor: 1
- DC current: 16.5 A
- AC current: 8.3 A
- protection class: IP23M
- quality class: B
- efficiency class: G2
- electrical insulation class: I
Engine:
- engine type: R225-V
- single-cylinder, four-stroke engine
- fuel type: unleaded petrol
- oil type: SAE 15W-40
- start: manual and electric
- engine capacity: 224 cm3
- max engine power: 5.3 kW
- max engine speed: 3600 rpm
- air cooling
- compression ratio: 10.5:1
- fuel tank capacity: 8.3 l
- oil tank capacity: 0.55 l
- spark plug type: F6RTC
Device:
- operating temperature: 0-40˚C
- max operating altitude: 1000 m above sea level
- clear control panel with indicators
- AC and DC protection
- eco mode
- carrying handle
- 2 transport wheels
- 2 230 V power sockets
- noise level: 94 dB
- dimensions: 590 x 456 x 511 mm
- weight: 45 kg
Usage warnings:
Warning 1. Read the operating instructions and labels before starting work. 2. Attention! Exhaust gas is toxic. Do not operate the generator indoors without adequate ventilation. 3. Keep children away from the generator. 4. Do not refill fuel and oil while the generator is running. 5. If the generator will be placed in a closed room, measures must be taken to prevent fire and explosion. 6. Do not connect the generator to the home electrical network. 7. Do not use the generator in high humidity conditions. 8. Keep flammable products away from the generator. 9. When refueling: - stop the engine, - do not smoke, - do not spill fuel.
