| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRE |
| Measuring range | 0-200 mm |
| Measurement accuracy | ±0.02 mm, ±0.001" |
| Metric scale | yes |
| Inch scale | yes |
| Material | stainless steel |
| Reading type | electronic |
| Display type | liquid crystal LCD |
| Reading resolution | 0.01mm, 0.0005" |
| Power supply | battery |
| cell type | 3V; CR2032 |
| Battery capacity | 220 mAh |
| Working temperature range | 5~40 ˚C |
| Storage temperature | -20 ~ +60 ˚C |
| Application | performing height measurements of various objects and elements, for scribing and marking |
| Symbol | YT-72280 |
An electronic altimeter is a precise tool designed for measuring the height of various objects and elements, tracing and marking surfaces. It is used in mechanical workshops, measurement laboratories, and assembly work where high accuracy and repeatability of results are required.
- measurement range from 0-200 mm
- measurement accuracy ±0.02 mm|±0.001" and reading resolution 0.01 mm|0.0005" ensure reliable results even for measurements requiring high precision
- convenient electronic reading on a liquid crystal LCD display in metric and imperial scale
- body made of high-quality stainless steel with high resistance to deformation and wear ensures durability, stability, and repeatability of measurements
- operating temperature range of 5-40°C allows for use in standard workshop and production conditions
- storage temperature range from -20 to +60°C
- powered by a 3V battery (CR2032 type) with a capacity of 220 mAh ensures long and stable device operation
