| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRE |
| Measuring range | 0-300 mm |
| Measurement accuracy | ±0.02 mm, ±0.001" |
| Metric scale | yes |
| Inch scale | yes |
| Material | stainless steel |
| Reading type | traditional |
| Reading resolution | 0.01mm, 0.0005" |
| Working temperature range | 5~40 ˚C |
| Application | performing height measurements of various objects and elements, for scribing and marking |
| Symbol | YT-72272 |
An altimeter is a precise tool designed for measuring the height of various objects and elements, tracing, and marking on work surfaces. It is used in mechanical workshops, measurement laboratories, and assembly work where high accuracy and repeatability of results are required.
- measuring range - depending on the model - from 0-200 mm up to 0-500 mm allows to choose the appropriate variant for the type of work being performed
- measurement accuracy ±0.02 mm|±0.001" and reading resolution 0.01 mm|0.0005" guarantee reliable results even for measurements requiring high precision
- reading done in a traditional way, using metric and inch scales
- solid body made of high-quality stainless steel with high resistance to deformation and wear ensures durability, stability, and repeatability of measurements
- operating temperature range of 5-40°C allows for use in standard workshop and production conditions
