| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRF |
| Max. working pressure | 0.5 MPa |
| Recommended working pressure | 0.5 MPa |
| Required air flow | 60 l/min |
| Crushing pressure | 1255 kg |
| Air connection diameter (PT) | standard |
| Air supply hose inside diameter | 3/8" (9.5 mm) |
| Rivets diameter | 4, 4.8, 5, 5.4, 6, 6.4 mm |
| Jaw quantity | 3 |
| Spare jaws quantity | 3 |
| Max. piston stroke | 20 mm |
| Acoustic pressure | 87.2 ± 2.3 dB(A) |
| Acoustic power | 94.5 ± 3.0 dB(A) |
| Vibrations | 0.54 ± 0.15 m/s² |
| Weight | 1.6 kg |
| Symbol | YT-36177 |
Designed for permanently joining metal parts with rivetsórivets in steel, stainless steel and aluminum.
- The weighted pressure connection allows the riveter to rotate freely
- The durable 3-jaw system ensures fast and efficient riveting
./li>- interchangeable endsós allow you to work with rivets of different diameters
- Range of rivetsós: 4–6.4 mm
- low air consumption
- ergonomic and easy-to-use design
.- 3 spare jaws
- bucket for broken mandrels
- hanger in housing
Usage warnings:
Warning! Always use personal safety equipment at work.
