| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRF |
| Max. working pressure | 0.63 MPa |
| Required air flow | 141 l/min |
| Rotations | 20000 min⁻¹ |
| Air connection diameter (PT) | standard |
| Air supply hose inside diameter | 3/8" (9.5 mm) |
| Max. toolholder size | 10 mm |
| Casing material | composite |
| Speed adjustment | yes |
| Rotation switch | no |
| Rotated air exhaust | 360˚ |
| Acoustic pressure | 92.0 ± 3.0 dB(A) |
| Acoustic power | 103.0 ± 3.0 dB(A) |
| Vibrations | 6.2 ± 1.5 m/s² |
| Weight | 0.66 kg |
| Set includes | pneumatic drill, air inlet connector |
| Symbol | YT-09695 |
Professional pneumatic drill powered by a stream of compressed air under pressure. Designed for drilling in metal, wood, plastic and when it is necessary to drill without impact. It is perfect for use in spaces with limited maneuvering area. Used in automotive service and industry.
- bore diameter: 10 mm
- pressure: 0.63 MPa
- power output: 141 l/min
- max speed: 20,000 rpm
- max./min
- infinitely variable speed control
- rotary air blower 360°
- lightweight composite housing and small size for comfortable work
- low vibration
- lock on switch protects against unwanted activation
- standard connection
