| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRF |
| Connecting elements type | staples, nails |
| Connecting elements length | 16-40 mm |
| Connecting elements dimensions | 16-40x1x5.7 (staples), 10-40x1x2 (nails) mm |
| Max. working pressure | 0.8 MPa |
| Recommended working pressure | 0.4-0.8 MPa |
| Air connection diameter (PT) | standard |
| Air supply hose inside diameter | 3/8" (9.5 mm) |
| Dispenser capacity | 100 szt. |
| Dimensions | 55x196x245 mm |
| Body material | aluminum |
| Handle material | rubber |
| Functions | sequential operating mode |
| Fuse | yes |
| Acoustic pressure | 86.3 ± 2.5 dB(A) |
| Acoustic power | 99.3 ± 2.5 dB(A) |
| Vibrations | 2.2 ± 0.89 m/s² |
| Weight | 1.45 kg |
| Application | upholstery, carpentry, finishing works |
| Symbol | YT-09206 |
A professional and reliable pneumatic stapler designed for intensive upholstery, assembly, and carpentry work. Solid construction and practical features ensure fast, safe, and precise joining of materials - both in serial work and for precise tasks.
The stapler handles staples and nails ranging from 16 to 40 mm in length. Thanks to two types of connectors, it works well with thin upholstery fabrics as well as harder wooden materials.
The pneumatic power supply with a maximum operating pressure of 0.8 MPa ensures constant driving force and high efficiency. The standard air connection and compatibility with a 3/8" (9.5 mm) hose make the tool easily compatible with most compressors available on the market.
- length of connectors: 16-40 mm
- dimensions of connectors: 16-40 x 1 x 5.7 mm (staples), 10-40 x 1 x 2 mm (nails)
- max. operating pressure: 0.8 MPa
- air connection diameter: standard
- internal diameter of air supply hose: 3/8" (9.5 mm)
- container capacity for 100 staples or nails allows for longer work without frequent refills
- sequential mode function allows for controlled, rhythmic driving of connectors
- safety fuse minimizes the risk of accidental tool activation
- aluminum body ensures high resistance to mechanical damage while maintaining a low device weight, especially appreciated during long hours of work
- anti-slip rubber handle provides a secure grip and reduces vibration transfer to the hand
- compact dimensions: 55 x 196 x 245 mm allow for easy maneuvering, even in hard-to-reach places
- weight: 1.45 kg
